Movable Glass Partition Wall

  • Panglass Auto Electric Double Glazed Movable Partition Wall System

System Information

A Simple and Transparent Touch to Spaces

What is it? What are its properties? Where is it used?

Panglass Auto is Turkowall's semi-automatic double glazed glass movable wall system. This system, on one hand, functions as a wall with high acoustic sound insulation dividing the space, on the other hand, it eliminates the borders with its visual lightness and transparency. While providing privacy exactly as you want it, it also allows you to benefit from natural light with visual freedom.

Our Panglass Auto system is manufactured with double glazing and electrically. Special aluminum guillotine profiles positioned above and below the system create fully insulated walls by automatically tightening and opening movements with electrically operated motors.

confirmation iconTransparentconfirmation iconNatural Lightingconfirmation iconAestheticconfirmation iconMinimal

Technical detail

Panglass Auto is our double glazed semi automatic movable partition wall system that we have developed for our customers who demand transparency and privacy at the same time. You can use this system to close all openings. It works easily even in spaces with high ceilings, with laminated tempered glasses and solid aluminum construction that we use on both surfaces. The system has compact motors that work with 12 or 24 volt weak current electrical power. The lower and upper working spaces and the telescopic module on the last panel are opened and closed with the push and pull movement of the motors. Our system, which offers high acoustic comfort, can also be manufactured with a blind between two glasses, according to your request.

System Components
Panglass Auto Panel Components
Double glazed folding movable partition door
Double glazed folding movable partition door
1 - reel/roller
2 - Rail
3 - Upper acoustic comfort barrier
4 - Acoustic junction wedge
5 - 4/6/8 mm glass surface
6 - Automatic guillotine mechanismı
Panglass Auto System Sections

Our Panglass Auto system has glass-to-glass joint details.

Vertical Section Detail
Panglass basic movable partition wall vertical section
Horizontal Section Detail (plan)
Panglass basic movable partition wall plan
Panglass basic movable partition wall
Panglass basic movable partition wall
Panglass basic mobile partition wall

Panglass Auto Acoustic Components

Although the main components of the Panglass Auto glass movable partition wall system are glass and aluminum, it promises a significant acoustic comfort. Mid-level sound insulation is provided with rubber wicks integrated into the specially developed vertical and horizontal joint profile. It guarantees sound insulation up to 42 decibels if other components of the space are compatible.

Acoustic movable partition wall systems

Acoustic Elements

Acoustic junction wedge (4 corners on each panel): Standard

Vertical sound insulation barrier (Guillotine): Standard

Horizontal concave convex aluminum caps: Standard

Horizontal concave and convex insulation cords: Standard

Sound insulation level: 30 dB and 42 dB

Specifications Table

Panglass Auto glazed movable wall system is our double glazed system with its own special aluminum frame. There are movable insulation profiles on the top and bottom of the panels, and thanks to the guillotine system, these profiles become active and apply pressure to the ceiling and floor, thus closing the wall completely. Our Panglass Auto system is recommended wherever visual transparency but sound privacy or acoustic comfort are required.

Panglass Auto glass movable wall system works semi-automatically. In this system, each panel is locked individually and the system provides a high level of security. The technical properties of the glasses used can be changed in accordance with the project, so that the insulation and light control values of the entire system can be manipulated. In this way, an insulated and transparent wall is formed. Sandblasting and coating can be applied in any color in accordance with the project and space design.

Painted windows or double-glazed blinds can be preferred. Frame profiles can be painted in the desired color.

Panglass pine panel

Technical Tools

You can download the technical design tools, plan, elevations and system sections of the Panglass Auto glazed semi-automatic movable partition wall system in CAD and PDF formats and use them easily in your projects.

Panglass double glazed semi-automatic movable wall system vertical section
System Vertical Sections
dwg iconu
pdf iconu
Panglass Horizontal section of double glazed semi-automatic movable wall system
System Horizontal Sections (plan)
dwg iconu
pdf iconu
Movable-folding-partition-park-options
Parking Types
dwg iconu
pdf iconu
Movable partition wall ceiling carrier system details
Ceiling Connection Details
dwg iconu
pdf iconu
Movable wall systems in-ceiling advanced acoustic insulation details
High Acoustic Insulation Details
dwg iconu
pdf iconu
Movable wall systems in-ceiling carrier construction options
Load bearing construction
dwg iconu
pdf iconu

Technical specifications

Panglass Auto is our double glazed semi-automatic movable partition wall system that we have developed for our customers who demand transparency and privacy at the same time. You can use this system to close all openings. It works easily even in areas with high ceilings thanks to the laminated tempered glass we use on both surfaces and its solid aluminum construction. The system has compact motors that work with 12 or 24 volt weak current electrical power. The lower and upper working spaces and the telescopic module on the last panel are opened and closed by the push and pull movement of the motors. Our system, which offers high acoustic comfort, can also be manufactured with a blind between two glasses, according to your request.

Project

Panglass Auto: Double glazed movable walls provide soundproof space. Our Panglass Auto Electric double glazed movable partition system offers you the possibility to use both a transparent wall and a closed wall with blinds that can be integrated into the panel.
